SKU: HiWay-5S Category: Tags: , Brand:

HiWay-5S Vehicle And Yacht Booster All UK Networks

£950 £799


All UK Networks Voice and Data

  • Automatic gain control function
  • CoverageArea up to 500 Sqm
  • Quality built, strong and durable
  • Conforms to ETSI&3GPP standards

Share it:

HiWay-5S is the ultimate vehicle and Yacht signal enhancer ever built. it is configured to improve signal for all UK and European Networks transmitting on 800/900/1800/2100/2600 MHz frequencies in all types of vehicles stationary or in motion,yachts/ships sailing in the sea, mobile homes and cabins.

 It covers any indoor area up to 500 square meters(open space area) and is guaranteed to supply great communication experience with clearer calls and higher mobile data speeds than ever. HiWay-5S auto-adjusts to best signal output within 1 minute of switching it on.

Key Features

  • Networks: EGSM900+DCS/LTE1800+WCDMA2100+LTE800+LTE2600 MHz
  • Coverage: up to 500 sqm
  • Kit with outdoor directional antenna and cable
  • Intelligent and informative LCD display
  • Smart AGC & MGC functions
  • Officially CE- and RoHS-certified
  • 3 Year Warranty
  • 15 Days Money Back assured
  • 15-25 Simultaneous users

Certifications

All our Boosters are certified under the UK and EU safety Laws

Hi13-3S Voice & Data – 1000 sqm2

PRODUCTS SPECIFCATIONS

Coverage Area 500 m²
Application Home and Office Building
Network Type Calls, 3G / UMTS, 4G / LTE
Frequency 800 MHz (4G/LTE), 900 MHz (GSM/EGSM), 1800 MHz (DCS/LTE), 2100 MHz (3G/WCDMA), 2600 MHz (4G/LTE)
Frequency Range 832~862MHz (Uplink) 791~821MHz (Downlink), 880~915MHz (Uplink) 925~960MHz (Downlink), 1710~1785MHz (Uplink) 1805~1880MHz (Downlink), 1920~1980MHz (Uplink) 2110~2170MHz (Downlink), 2500~2570MHz (Uplink) 2620~2690MHz (Downlink)
Number Of Bands Five Band
Max. Gain 55dB (Uplink) – 60dB (Downlink)
MGC (Step Attenuation) ≥ 16dB / 1 dB step, dip switch control
Intelligent AGC (ALC / ISO) ≥42 dB / ≥42 dB
Gain Flatness Typical ≤5 dB (P-P)
Noise Figure @ Max. System Gain Typical ≤5 dB
V.S.W.R Typical ≤2
Group Delay ≤ 1 μs
Frequency Stability ≤0.01 ppm
Power Supply Input AC100~240V.50/60Hz, Output DC12V/7A
Power Consumption ≤24W
Input & Output Impedance 50 ohm
LCD Display Frequency, Gain, Output Power, ALC, ISO, etc.
Indication LEDs No
I /O Port Type N-Female
Dimensions 153 x 246 x 36mm/ 6 x 9.7 x 1.4inch
Booster Weight 1.8 kg
Booster Weight with KIT 5 kg
Operating Temperature -10ºC~+55ºC
Storage Temperature -10ºC~+80ºC
Relative Humidity 5% – 95%
Barometric Pressure 55 kPa -106 kPa
Environment Conditions IP40



Coverage

Large Homes (Up to 500m²), Vehicles & Fleets

Network

GiffGaff, iD Mobile, PlusNet Mobile, Sky Mobile, Smarty, Tesco Mobile, Virgin, EE, O2, Vodafone, Three

Speed

2G | Voice, 3G, 4G / LTE
