Multi-Band Omni (Easy Install)

£55


Frequency Range 698-806/806-960/1710-2700MHz
Gain 2.2±0.5/3.5±0.5/4.5±1.0
Polarization Horizontal


Share it:

Multi-Band Omni

Our WB Multiband Omni Kit is an easy to install accessory and it transmits signals in a 360 degrees radius. It is mostly designed to install in a suspended ceiling and it is proven to provide a wider signal coverage than the whip or panel antenna.

The Omni antenna is compatible with all Uk and Worldwide Network 800MHZ/900MHZ/1800MHZ/2100MHZ/2600MHZ  and also works with all our boosters.

It is easy to install and with its sophisticated looks, it can easily be installed in any property.

Please consult our technical/sales team if you need to add an extra antenna to your connections.

Frequency Range 698-806/806-960/1710-2700MHz
Gain 2.2±0.5/3.5±0.5/4.5±1.0
Polarization Horizontal
VSWR ≤1.5
PIM, 3rd Order, 2 x 2 W ≤-140
Input Impedance 50Ω
Maximum Power 50W
Connection Type N-Female
Weight 0,3 kg
Dimension Φ220*18mm
Lighting Protection DC Ground
Mounting Kit Ceiling, via hole (standard)
Operational Temperature -55~60℃
Operational Humidity <
Weight 0.3 kg
Dimensions 22 × 18 cm
